Networking

(For a more dry and technical explanation, check out the networking docs at https://docs.clan.lol/guides/networking/)

Every now and then people ask me, what is the best overlay network/VPN? And each time I give them a long and sad answer: that all of them have different tradeoffs and there’s no one size that fits all.

Here’s a quick idea of what I mean:

(This table is subjective, but is here to make a point)

There are some more VPN solutions that I haven’t tried yet, but there is no ultimate solution and each comes with certain pros and cons. For this reason we have built a network abstraction into Clan that will choose the best network for all the actions you want to run on a remote machine.

How it works

First, you must enable a network-capable Clan Service. At the time of writing, there are only two (because I’ve been too lazy to add more): tor and an internet service. The tor service connects through the Tor network to a hidden service running on the target machine. The internet service requires manual configuration of IP addresses.

Lets look at an example:

...
  inventory.instances = {
    tor = {
      roles.server.tags.nixos = {};
    }
  }
...

This would enable the tor service on all nixos machines.

A network is then exposed with a priority and an attribute set of peers into the global flake, which you can examine with the following command:

clan select 'clan.exports.instances.*.networking.{priority,peers}'

The output should look something like this:

{
  "blabla": {}
  "tor": {
    "priority": 10,
    "peers": {
      "my_cool_machine": {
        SSHOptions": [],
        "host": {
          "var": {
            "file": "hostname",
            "generator": "tor_tor",
            "machine": "my_cool_machine"
          }
        },
        "name": "my_cool_machine"
      }
    }
  }
}

You can see the default priority of 10 and a list of peers corresponding to your machines.

A host entry can either be a plain value or a var (as above) which gets decrypted on demand when used. We do this to prevent our Tor hidden service hostnames from being exposed publicly

NOTE: If you install a machine after enabling the tor service you will have to manually update the machine with --target-host one last time, after which the tor vars for that machine will to be generated and deployed.

You can try out the new networking with:

clan ssh my_cool_machine

This should log you into the target machine via Tor (or something faster if you have another network configured). If you have no Tor daemon running on your system, it will start one for the duration of the connection (thats pretty rad).

The JSON output from the clan select command earlier is a bit annoying to type and the output a bit hard to read, so for this reason we built a nicer interface for interacting with networks:

clan network list

This prints a list of all the networks you have configured. For our test case it would look like this:

Network       Priority  Module      Running   Peers
---------------------------------------------------
tor           10        tor         No        my_cool_machine

(This is only cool with multiple networks).

We can now have multiple networks configured and let the Clan cli decide on the best way to reach our machines via those networks from our admin machine.

What is still missing?

Sadly, a lot. Here is a short list of the top of my head:

• Currently only works for admin -> machine connections. Ideally we want them for machine <-> machine connections as well
• More network modules like mycelium and zerotier
• Userspace networking, like the Tor daemon with on-demand starting. We want to have the same behaviour for all kinds of networks.

There’s likely more features I can’t think of which are missing, so stay tuned for more networking related blogposts in the future :)
